Rotory Printing Machine for Cotton Fabric

TYPE: LMV50D

1.DESCRIPTION OF MACHINE

LMV50D ROTARY PRINTING MACHINE IS WIDELY USED TO PRINT DIFFERENT KIND OF DESIGNS ON FABRIC, THE DESIGN MADE BY THIS MACHINE IS HIGH PRECISION AND GOOD QUALITY.

2.SPECIFICATION OF MACHINE

1、WORKING WIDTH：2400MM

2、MOULD PERIMETER：640MM 820MM 912MM 1018MM

3、COLOR: 12SETS (ADJUSTABLE)

4、SPEED ：5-80M/MIN

5、PRECISION：MANUAL

6、ADJUSTABLE RANGE ：CROSSWISE:12MM，  SLANT:15MM, LENGTH WAYS: UNLIMITED

7、HEIGHT CLEARANCE STROKE ：MAX 6MM

8、PRECISION：±0.2MM

9、THE MAGNETIC SEAT: ADOPT MAGNETIC SEAT

10、POWER：TOTAL 102KW，PRINTING ＜50KW

11、PRINTING CONDUCTION BAND WIDTH ：2700MM

11、OVERALL DIMENSIONS（LXWXH）：16.5M×6.2M×4.2M

12、STANDARD NICKEL NET LENGTH ：3180MM

13、STANDARD BAR LENGTH ：3080MM

14、WEIGHT ：30T

15、OPERATING SIDE: LEFT OR RIGHT

3. APPLIACATION OF MACHINE
