Material: frame for stainless steel profile, panel 304 plate
Taiwan Sanacer inverter (4KW*4 sets, 0.75KW*9 sets)
Wuxi Yuanda fan (return fan 5.5KW*2 sets, cooling fan 11KW*2 sets)
Schneider Electric + Taiwan Yonghong PLC+ Beijing Kunlun on-state touch screen
Working speed 10-40m /MIN
Working temperature below 130 degrees, steam pressure >4kg
The total power of the machine: 45KW, the weight of the machine: about 10 tons
Dimensions: length 126950mm* width 4640mm* height 5190mm
Air compressor pressure: 4-7kg /C㎡
Heating method: steam or natural gas (with 300000 kcal Wigson burner)
4 cylinders are equipped with steam injection pipes
